Name of vessel :

USA RIVER

GT :

4606

Type :

Oil tanker

GT: (for calcul. of fees, based on GT)

3655

Owners :

Castaneda Shipping Ltd. Valletta, Malta

NT :

2036

Flag :

Malta

Displacement :

9380 mt

Port of Registry :

Valletta

Deadweight :

6600 mt

Official Number :

6989

Light weight :

2780 mt

Call Sign :

9HTB6

Overall length :

129.3 m

IMO Number :

9175183

Length b.p.p. :

123.2 m

Satcom C :

4 248 863 10 / 11

Beam moulded :

16.5 m

Satcom M:

7 626 088 49 / 50 (voice / fax)

Maximum draft :

4.98 m

MMSI Number:

248 863 000

Depth moulded :

6.80 m

Builder's Yard :

JSC Volgograd Shipping Plant. Russia

Draught :

4.98 m

Year built :

2000

Hull No. :

304

Cargo tanks:

10TKs (5-PS, 5-SB)
+ 2 sloptanks

Classification :

Rus. Maritime Registry; Lloyds Registry

Segregations:

5 full segr., manually operated

Class Notat.RMR :

KM 3 I A 1 oil tanker (ESP)

Vapour emission return:

Installed

Class Notat.LR:

100 A1 Oil tanker (double hull) ESP
IWS, LL, Ice Class ID, LMC, UMS

Full depth C.Tk. sounding pipes:

Yes

Closed loading:

Yes

Class ID :

980179

C.Tk coating:

"International INTERLINE 504"-Epoxy

Main engines :

1 nonreversible gearboxed t/charged
MaK 6M25M, 4 cycles

C.Tk heating:

Stainless Steel Coils

Capacity:
-excluding slop tks:
-slop tanks p/s:
Total incl. slops:

7384 m³
198 m³
7582 m³

Power, nominal :

1800 kW / 2448 B.H.P. at 750 R.P.M.,

propeller - 230 R.P.M.

Speed/consump :

10.5 / 8.0 (laden), 11.5 / 8.0 (bal)
MGO-0.750mt/d, cargo disch.-1.35 mt/d

Fire fighting :

water/foam / CO2 fire-fighting
2 fire pumps BBLG, Q=160/100m³/h
1-emerg.pump ILCS50/250, Q=63m³/h

Cargo pumps:

5 deepwell, el.driven

MARFLEX - MPD 125

Capacity:

Variable speed, Q=0~180 m³/h

Anti-pollution :

oil spill kit OPA-90; OWS:DVZ 500-VC
Q=0.5m3/h; STP: MINI Q=4-6 m³/d

Slop TK pumps:

2 - deepwell MBDP, el driven

Capacity:

Variable speed, Q=0~70 m³/h

Mooring equipment:

2 anch. windlasses S=12mts/min

Ballast tanks :

N°1-10,12

1 moor.winch S=12 mts/min

Ballast capacity :

3554 m³

Steering gear :

2RA 185-35, Pmax=185 kN, 3 rudders

Ballast pumps:

2 deepwell, el.driven, MARFLEX

Bow thruster:

ULSTEIN 45TV; 240 kW

Capacity:

Variable speed Q=0~300 m³/h,

Hose Handl. Crane:

1x 2.0 Ton x 12.5m

Fresh water :

121.2 mt

Electrical Power :

3 aux.eng. VOLVO PENTA, TAMD 122A
6 cylinders, 247kW at 1500 R.P.M.
Gener. Sets STAMFORD - HC M434 E1
3-ph. 400/231 V 50 Hz 290 / max 341 kVA

Boiler water:

27 mt

Bunker capacity:

IFO - 256 m³
MGO - 74.1 m³

Boilers:

2 Aux. Boilers:

1600 kg/hr, WP=7.0 bar

E.G.Economizer:

750 kg/hr, WP=7.0 bar
