Name of vessel :

GT :

4606

Type :

Oil tanker

GT: (for calcul. of fees, based on GT)

3655

Owners :

Celerina Shipping Ltd. Valletta, Malta

NT :

2055

Flag :

Malta

Displacement :

9380 mt

Port of Registry :

Valletta

Deadweight :

6600 mt

Official Number :

6583

Light weight :

2780 mt

Call Sign :

9HIU6

Overall length :

129.3 m

IMO Number :

9175169

Length b.p.p. :

123.2 m

Satcom C :

424855810

Beam moulded :

16.5 m

Satcom M:

762028032 / 33 (Voice / Fax)

Maximum draft :

4.98 m

Builder's Yard :

JSC Volgograd Shipping Plant. Russia

Depth moulded :

6.80 m

Year built :

1999

Draught :

4.98 m

Hull No. :

302

Classification :

Rus. Maritime Registry; Lloyds Registry

Cargo tanks:

10TKs (5-PS, 5-SB)
+ 2 sloptanks

Class Notat.RMR :

KM 3 I 1 A 1 oil tanker (ESP)

Segregations:

3 full segregations

Class Notat.LR:

100 A1 Oil tanker (double hull) ESP Black Sea, Mediterranean, European waters (excl. Bay of Biscay), North Sea and Baltic service area in association with defined operational service limits not to exceed 200 nautical miles from coast 400 nautical miles from sheltered waters/safe haven and max.wave height 8.5 metres (max. significant wave height 4.5 metres),
IWS, LL, Ice Class ID, LMC, UMS

Vapour Emission Control Syst.:

Installed

C.Tk coating:

"International INTERLINE
504"-Epoxy

C.Tk Heating:

Stainless Steel Coils

Capacity:

excluding slop tks:

7384 m³

Class ID :

970139

slop tanks p/s:

198 m³

Main engines :

1 nonreversible gearboxed t/charged
MaK 6M25M, 4 cycles

total incl. Slops:

7582 m³

Cargo pumps:

5 deepwell, el.driven
MARFLEX - MPD 125

Capacity:

Variable speed, Q=0~180 m³/h

Fire fighting :

water/foam / CO2 fire-fighting
2 fire pumps BBLG, Q=160/100m³/h
1-emerg.pump ILCS50/250, Q=63m³/h

Slop TK pumps:

2 - deepwell MBDP, el driven

Capacity:

Variable speed, Q=0~70 m³/h

Anti-pollution :

oil spill kit OPA-90; OWS:DVZ 500-VC
Q=0.5m3/h; STP: MINI Q=4-6 m³/d

Ballast tanks :

N°1-12

Ballast capacity :

3645 m³

Mooring equipment:

2 anch. windlasses S=12mts/min
1 moor.winch S=12 mts/min

Ballast pumps:

2 deepwell, el.driven, MARFLEX

Steering gear :

2RA 185-35, Pmax=185 kN, 3 rudders

Capacity:

Variable speed Q=0~300 m³/h,

Bow thruster:

ULSTEIN 45TV; 240 kW

Fresh water :

30.2 mt

Hose Handl. Crane:

1x 4.0 Ton x 12.5m

Boiler water:

27 mt

Electrical Power :

3 aux.eng. VOLVO PENTA, TAMD 122A
6 cylinders, 247kW at 1500 R.P.M.
Gener. Sets STAMFORD - HC M434 E1
3-ph. 400/231 V 50 Hz 290 / max 341 kVA

Bunker capacity:

IFO - 256 m³
MGO - 52.4 m³

Boilers:
2 Aux. Boilers:
E.G.Economizer:

1600 kg/hr, WP=7.0 bar
750 kg/hr, WP=7.0 bar

Managers :

ABC Maritime AG
Rue Perdtemps 1
CH-1260 NYON
Switzerland

Tel ( + 41-22) 365 71 00
Fax ( + 41-22) 365 71 11
E-mail abc@abcmaritime.ch
Tlx 419 907 abc ch

Note, all particulars are given in good faith, but are not guaranteed.
