M/V REALMAR / ex DOCEMAR
General Information: |
Tonnage & Dimensions: |
||||
Name of vessel : |
REALMAR (ex. DOCEMAR) |
GRT : |
41'016 |
||
Type : |
Bulk Carrier |
NRT : |
24'735 |
||
Owners : |
REALMAR SHIPPING CO., LTD |
Displacement sum-.draft SW : |
88'874 mt |
||
Flag/Port Registry: |
Malta, Valletta |
Deadweight sum.-draft SW: |
75'631 mt |
||
Registry Nr.: |
6778 |
Light-Ship weight : |
13'243 mt |
||
Call Sign/SAT-C Nr: |
9HOY6 / 4248710 / 11 |
LOA : |
241.885 m |
||
IMO Nr.: (Lloyd's ) |
8124278 |
Length b.p.p. : |
233.760 m |
||
Builder's Yard : |
Verolme do Brazil, Rio De Janeiro |
Beam moulded : |
32.200 m |
||
Hull No / year built: |
B-77 / 1984 |
Draftsummer moulded : |
13.596 m |
||
Classification : |
B.V. Bureau Veritas |
Depth moulded : |
18.700 m |
||
Class ID N° : |
990X81 |
Freeboard summer : |
5.158 m |
||
| Class Notation : | l 3/3 + BULK
CARRIER ALT (HOLD 2 + 4 + 6 MAY BE EMPTY) ESP, DEEP-SEA, + MACH |
Cargo
holds : Nr. 1 Nr. 2 Nr. 3 Nr. 4 Nr. 5 Nr. 6 Nr. 7 Nr. 1-7 |
excl. hatch |
incl. hatch |
|
| Propulsion: | |||||
| Main engine: | 1 x reversible 2-stroke diesel engine | ||||
| Type: | M.E.P.-MAN K7SZ 70 / 150 CL | ||||
| Power : | MRPmax 15'715
h.p. at 120.0 rpm CRPcond. 13'358 h.p at 118.5 rpm |
Tank Top load : |
29,5mt/m2 |
||
| Propeller: | one fixed 4-blade, RH, diam 6100, pitch 4207mm | Hatch Cover load : |
|||
Speed & consumpt: |
Tank Capacities: |
||||
Steering gear : |
Hydraul.double flow, 4-Ram 1197Nm"SPERRY" |
Ballast tanks total capacity: |
23'623 m³ |
||
Mooring Equipment: |
Cargo hold N°4 SW ballast cap.: |
12'271 m³ |
|||
Windlass/Anchor: |
two (2) combined electr-driven Anchor/Mooring- winches, 120/50 KN, 46mt at 9 m/min |
Bunker capacity, IFO 180cst: |
2890 m³ |
||
MDO capacity : |
251 m³ |
||||
Anchor & Chain: |
2 HALL anchors 10595 Kg, chain diam. 78mm |
Fresh water tank capacity : |
244 m³ |
||
Mooring-winches: |
Four (4) double drum electric.-driven automatic |
Fresh water production (evap.): |
25 m³/day |
||
Electrical Installation: |
Cargo gear : | Gearless |
|||
Diesel Gen.N° 1&2: |
Type: MEP MAN G7V 23.5/33 ATL, 923 BHP at 600 RPM |
Life Saving: |
|||
Electr.-generator : |
General Electric, 440 V, 781 kVA, 60 Hz. 625 kW, |
Life Boats: |
Two(2) open type life boat |
||
Diesel Gen.N° 3: |
Type: MAN R8V 16/18 TL 720 BHP at 1800 RPM |
capacity: |
max. 32 persons |
||
Electr.-generator |
A.v.Kaick, 440 V 60 Hz. 610 kVA |
Life Rafts: |
(2x20)+(2x10)+(1x6) pers |
||
Emerg-Diesel Gen.: |
Cummins, NTTA 855G, 465 BHP at 1800 RPM, |
Fire fighting : |
|||
Electr.-generator : |
NEGRINI: 3-Ph., 440V, 60 Hz., 312 kVA, 250 kW |
El-driven fire-PP |
two centrif.-PP 240m³/hr |
||
Electrical mains: |
3-phase, 440 / 220 / 110 V, 60 Hz. |
Emerg. fire pump: |
one diesel-motor driven |
||
Steam production: |
CO2 installation: | 143 bottles for eng.room |
|||
Aux-Boiler: |
One (1) oil fired water tube boiler using IFO 180 |
Potrable extinguish.: | according to SOLAS |
||
Capacity: |
2200 Kg/hr dry sat.-steam at WP 7.0 bars |
||||
Exh-Gas Boiler: |
one(1) exh.-gas economizer, vertical smok tube |
||||
Capacity: |
2000 Kg/hr dry sat.-steam at WP 7.0 bars. |
||||
Managers : |
ABC Maritime AG |
Tel: ( + 41-22) 365 71 00 |
|||
| Note, all particulars are given in good faith, but are not guaranteed. |  |
||||
